Corsair AF120 SLIM 120mm PWM Fluid Dynamic Bearing Ventola - nero

The Corsair AF120 SLIM is a high-performance 120mm case fan designed for efficient cooling in tight spaces. With a slim 15mm profile, it fits easily in compact builds while delivering powerful airflow and static pressure. The fluid dynamic bearing ensures quiet operation and long life, making it ideal for both air and liquid cooling setups.

Advantages

Ultra-slim design (15mm) for space-constrained cases; PWM control for precise speed adjustment from 600 to 2000 RPM; fluid dynamic bearing for low noise and extended durability; includes mounting screws for easy installation.

Suitable for

• Small form factor PC builds
• CPU cooler or radiator fans
• Case exhaust or intake in tight spaces

Key specifications

• Fan size: 120mm
• Thickness: 15mm
• Bearing: Fluid Dynamic Bearing
• Speed: 600 - 2000 RPM
• Airflow: 13.8 - 56.3 CFM
• Static pressure: 0.2 - 1.9 mmH2O
• Noise: 5 - 27.5 dBA
• Connector: 4-pin PWM
• Voltage: 12V DC
• Current: 0.15A
• Power: 1.8W
• LED: No
• MTTF: 60,000 hours
• Cable length: 300mm
• Blades: 7

Recommendations

For optimal cooling performance, pair this fan with a PWM-capable motherboard or fan controller. Ensure your case supports 120mm fans with 15mm thickness.
