DSIT CAT 6 cavo di rete LSOH - S/FTP - 50 metri - rosso (DC-S65-500)

For installations where fire safety and signal integrity are non-negotiable, this DSIT CAT 6 cable stands apart with its LSOH jacket and S/FTP shielding. Unlike standard PVC cables, it emits very low smoke and zero halogens when exposed to flame, making it suitable for public buildings, data centers, and office environments with strict safety codes. The screened/foiled twisted pair construction rejects electromagnetic interference, ensuring clean 1 Gigabit Ethernet transmission over the full 50-meter length.

Highlights

• Category 6 performance with 250 MHz bandwidth
• S/FTP shielding: overall braided screen plus individual foil per pair
• LSOH (Low Smoke Zero Halogen) jacket for enhanced fire safety
• Solid bare copper conductors, 23 AWG, 4 pairs
• Supports 10BASE-T, 100BASE-TX, and 1000BASE-T
• 100 Ohm impedance, compliant with ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2
• Bulk cable, unterminated, 50 meters in red

In daily use

This cable is intended for permanent installation in walls, conduits, or cable trays. Its solid core conductors provide stable performance over long distances, while the LSOH jacket reduces toxic emissions in case of fire. The red color allows easy identification in complex cable runs. With an outer diameter of approximately 6.5–7.5 mm, it fits standard Cat 6 connectors and patch panels.

Full specifications

• Brand: DSIT
• Model: DC-S65-500
• MPN: DC-S65-500
• EAN: 8719956628634
• Cable type: Network Installation Cable, Cat 6
• Shielding: S/FTP (Screened/Foiled Twisted Pair)
• Jacket material: LSOH (Low Smoke Zero Halogen)
• Length: 50 meters
• Color: Red
• Conductor material: Bare Copper
• Conductor gauge: 23 AWG
• Number of pairs: 4
• Max bandwidth: 250 MHz
• Max data rate: 1 Gigabit Ethernet (1000BASE-T)
• Compatibility: 10BASE-T, 100BASE-TX, 1000BASE-T
• Impedance: 100 Ohm
• Application: Indoor, Data Centers, Office Networks
• Fire safety: Reduced smoke and halogen-free
• Construction: Solid core
• Outer diameter: 6.5 - 7.5 mm (approx.)
• Standards compliance: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2
• Termination: Unterminated (bulk cable)

Final note

Choose this DSIT cable when safety regulations demand low-smoke, halogen-free materials without compromising on Cat 6 performance. The S/FTP shielding ensures reliable gigabit connectivity even in electrically noisy environments.
