DSIT Cavo patch di rete Cat 6a S/FTP LSOH 30m bianco

Experience 10 Gigabit Ethernet speeds over 30 meters with this DSIT Cat 6a S/FTP LSOH cable. Engineered for high-density data centers and enterprise networks, it delivers 500 MHz bandwidth and superior shielding to eliminate crosstalk and EMI, ensuring flawless signal integrity for bandwidth-intensive applications.

Overview

The DSIT DC-6A2-300 is a premium Category 6a patch cable featuring S/FTP construction: each twisted pair is individually foil-shielded, and the entire cable is wrapped in a braided screen. This dual-layer shielding provides maximum protection against alien crosstalk and electromagnetic interference, making it ideal for 10GBASE-T networks up to 100 meters. The low smoke zero halogen (LSOH) jacket emits minimal smoke and toxic fumes in case of fire, meeting strict safety standards for enclosed spaces. With 26 AWG stranded copper conductors and gold-plated RJ45 connectors, this cable offers both flexibility and long-term reliability.

What stands out

• Cat 6a performance: supports 10 Gbps data transfer rates and 500 MHz bandwidth, future-proofing your network.
• S/FTP shielding: individual pair foils plus overall braid for superior noise immunity.
• LSOH jacket: low smoke, zero halogen for enhanced fire safety in offices, schools, and data centers.
• 30-meter length: ideal for long runs in server rooms, structured cabling, or connecting distant devices.
• Gold-plated contacts: corrosion-resistant RJ45 connectors maintain optimal signal quality.
• Compliant with TIA/EIA-568B wiring standard for universal compatibility.

Technical details

• Cable type: Ethernet patch cable
• Category: Cat 6a
• Shielding: S/FTP (Screened/Foiled Twisted Pair)
• Jacket material: LSOH (Low Smoke Zero Halogen)
• Length: 30 m
• Colour: White
• Data transfer rate: 10 Gbps
• Bandwidth: 500 MHz
• Connector type: RJ45 male to RJ45 male
• Conductor material: Copper
• Conductor gauge: 26 AWG
• Wiring standard: TIA/EIA-568B
• Number of pairs: 4 twisted pairs
• Impedance: 100 Ohm
• Connector plating: Gold-plated contacts
• Outer diameter: approx. 6.0 - 7.5 mm
• Fire safety compliance: IEC 60332-1, IEC 61034-2, IEC 60754-2
• Application: LAN, data center, home network

Our verdict

The DSIT Cat 6a S/FTP LSOH cable is a top-tier choice for professionals who demand maximum performance and safety. Its robust shielding and low-smoke jacket make it suitable for the most demanding environments, while the 30-meter length provides flexibility in installation. Whether you're upgrading a data center or setting up a high-speed home office, this cable delivers reliable, future-proof connectivity.
