Eaton FAZ-C2/1 interruttore automatico magnetotermico Type-C, 2 A, 1 polo 278549

Protect your electrical circuits from overload and short-circuit damage with the Eaton FAZ-C2/1 miniature circuit breaker. This 1-pole MCB with Type C tripping characteristic is designed for reliable protection in residential and commercial installations.

Who is it for

Electricians, panel builders, and maintenance professionals who need a compact, DIN-rail mounted circuit breaker for protecting cables and equipment in distribution boards.

Main features

• Rated current: 2 A
• 1-pole design (1 module width, 17.5 mm)
• Type C tripping characteristic (magnetic trip 5-10 times rated current)
• Short-circuit breaking capacity: 6 kA according to IEC/EN 60898-1
• Rated voltage: 230/400 V AC, 48 V DC per pole
• Mounting on DIN rail EN 60715
• Terminal capacity: 1-25 mm²
• Energy limiting class 3
• Electrical life: >10,000 operations, mechanical life: >20,000 operations
• Operating temperature range: -25 to +75 °C

Specifications

• Brand: Eaton
• Model: FAZ-C2/1
• MPN: 278549
• EAN: 4015082785499
• Rated current: 2 A
• Number of poles: 1
• Tripping characteristic: C
• Rated voltage AC: 230/400 V
• Rated voltage DC: 48 V per pole
• Short-circuit breaking capacity (Icn): 6 kA
• Frequency: 50/60 Hz
• Mounting type: DIN rail (EN 60715)
• Degree of protection: IP20 (terminals), IP40 (with cover)
• Standards: IEC/EN 60898-1, VDE
• Terminal capacity: 1-25 mm²
• Energy limiting class: 3
• Electrical life: >10,000 operations
• Mechanical life: >20,000 operations
• Operating temperature range: -25 to +75 °C
• Module width: 1 module (17.5 mm)

Tips

For optimal protection, ensure the breaker's rated current matches the load and the cable cross-section. Type C is suitable for circuits with moderate inrush currents, such as lighting and socket outlets.
