EATON FRBMM-C16/3/003-A RCBO, 16 A, 30 mA, Type-A, curva C, 3 poli + N, 6 kA, 4 moduli 170740

Combines residual current protection (30 mA, Type A) and overcurrent protection (C-curve, 16 A) in a single 4-module device, with a 6 kA breaking capacity for reliable circuit protection in residential and commercial installations.

Overview

The EATON FRBMM-C16/3/003-A is a residual current circuit breaker with overcurrent protection (RCBO) that integrates the functions of an RCD and an MCB. It is designed for three-phase plus neutral circuits, providing protection against earth fault currents, overload, and short circuits. The device is suitable for DIN rail mounting and occupies 4 module widths (72 mm).

What stands out

• Rated residual current of 30 mA with Type A sensitivity, detecting AC and pulsating DC fault currents.
• C tripping characteristic (5–10 × In) for circuits with moderate inrush currents, such as lighting and socket outlets.
• 6 kA rated breaking capacity (Icn) and energy limitation class 3 for safe interruption of short-circuit currents.
• Compact 4-module design saves space in distribution boards.
• Surge current withstand capability of 3 kA (8/20 µs) reduces nuisance tripping.

Technical details

• Rated current (In): 16 A
• Rated residual current (IΔn): 30 mA
• Number of poles: 3-pole + neutral (4-pole physical device)
• Rated voltage: 230/400 V AC
• Rated frequency: 50 Hz
• Rated switching capacity (Icn): 6 kA
• Short-circuit breaking capacity (Ics): 6 kA
• Residual current type: Type A
• Mounting type: DIN rail (EN 60715)
• Module width: 4 TE (72 mm)
• Energy limitation class: 3
• Surge current withstand capability: 3 kA (8/20 µs)
• Terminal capacity (solid wire): 1.5–25 mm²
• Terminal capacity (flexible wire): 1.5–16 mm²
• Degree of protection: IP20 (terminals), IP40 (installed)
• Operating temperature range: -25 °C to +40 °C

Our verdict

A dependable RCBO for three-phase circuits requiring combined residual current and overcurrent protection, with robust 6 kA breaking capacity and Type A sensitivity.
