EATON PFIM-63/4/003-G/F interruttore differenziale 63A 4 poli 30mA tipo G/F 187358

Residual Current Circuit Breaker (RCCB) with a rated current of 63 A and 4 poles, providing reliable protection against earth fault currents with a sensitivity of 30 mA. Its Type G/F characteristic ensures short-time delayed tripping and resistance to frequency converters, making it suitable for industrial applications.

Advantages

Short-time delayed tripping prevents nuisance tripping from transient surges. Frequency converter resistant design ensures stable operation in environments with variable speed drives. Compact 4-module width saves space on DIN rail.

Suitable for

• Industrial distribution boards
• Circuits with frequency converters
• Protection of personnel and equipment against residual currents

Key specifications

• Rated current: 63 A
• Number of poles: 4
• Rated residual operating current: 30 mA
• RCD type: G/F
• Rated voltage: 230/400 V AC
• Rated frequency: 50/60 Hz
• Rated conditional short-circuit current: 10 kA
• Surge current withstand: 3 kA (8/20 µs)
• Mounting: DIN rail
• Module width: 4 modules (70 mm)
• Degree of protection: IP20 (terminals), IP40 (installed)
• Operating temperature: -25 to +40 °C
• Terminal capacity: 1.5 - 35 mm²
• Standards: IEC/EN 61008

Recommendations

Ideal for protecting circuits with frequency converters where standard RCCBs may trip falsely. Ensure proper installation by qualified personnel.
