EATON PXF-63/4/003-A interruttore differenziale (RCCB), 63 A, 4 poli, 30 mA, tipo A

For installations where pulsating DC residual currents may occur, the EATON PXF-63/4/003-A offers dependable protection that goes beyond basic AC-only devices. This 4-pole RCCB is engineered to detect both sinusoidal AC and pulsating DC earth leakage currents, making it a robust choice for modern electrical systems with electronic loads.

Highlights

• Rated residual operating current of 30 mA for personal protection against electric shock
• Type A tripping characteristic: sensitive to AC and pulsating DC residual currents
• High 63 A rated current and 10 kA conditional short-circuit withstand capacity
• Compact 4-module DIN rail design for easy installation in distribution boards
• Complies with IEC/EN 61008, ensuring safety and performance consistency

In daily use

Installation is straightforward on a standard 35 mm DIN rail, with clearly marked terminals accepting solid or stranded conductors from 1.5 to 35 mm². The device operates reliably across a wide temperature range from -25 °C to +40 °C, and its IP20 terminal protection suits indoor electrical enclosures. A mechanical lifespan of 20,000 operations and electrical endurance of 10,000 cycles mean it will serve for years without degradation.

Full specifications

• Device type: Residual Current Circuit Breaker (RCCB)
• Number of poles: 4
• Rated current (In): 63 A
• Rated residual operating current (IΔn): 30 mA
• Residual current type: Type A
• Rated voltage (Un): 230/400 V AC
• Rated frequency: 50/60 Hz
• Mounting type: DIN rail
• Short-circuit withstand capacity (Icn): 10 kA
• Degree of protection: IP20 (terminals)
• Operating temperature range: -25 to +40 °C
• Terminal capacity (solid/stranded): 1.5 - 35 mm²
• Module width: 4 modules (70 mm)
• Rated impulse withstand voltage (Uimp): 4 kV
• Standards: IEC/EN 61008
• Electrical life: 10,000 cycles
• Mechanical life: 20,000 cycles
• Tripping characteristic: Instantaneous

Final note

With its Type A sensitivity and high current rating, the EATON PXF-63/4/003-A is a reliable guard against earth faults in commercial and industrial settings where electronic equipment is prevalent.
