EATON PXL-C10/1 interruttore automatico magnetotermico 10A 1 polo curva C 10kA (236055)

The EATON PXL-C10/1 is a single-pole miniature circuit breaker from Eaton’s PXL range, engineered to protect final circuits against overloads and short circuits. With a 10 A rated current and C tripping characteristic, this MCB delivers dependable performance in 230/400 V AC installations, making it an ideal choice for lighting and socket-outlet circuits.

Highlights

• Rated current 10 A, C-curve for controlled inrush
• 1-pole, 230/400 V AC operation
• 10 kA short-circuit breaking capacity (Icn)
• DIN rail mounting, 1 module width (17.5 mm)
• Screw terminals accepting 1–25 mm² conductors
• Compliant with EN 60898-1 and IEC 60898-1

In daily use

The compact single-module design saves space in distribution boards, while the C characteristic prevents nuisance tripping from motor starting or capacitor inrush. Standard screw terminals support solid and stranded conductors up to 25 mm², and the breaker operates reliably across -25 °C to +75 °C, suitable for most building installations.

Full specifications

• Rated current (In): 10 A
• Number of poles: 1-pole
• Tripping characteristic: C
• Rated voltage (Ue): 230/400 V AC
• Rated short-circuit breaking capacity (Icn): 10 kA
• Frequency: 50/60 Hz
• Mounting type: DIN rail
• Degree of protection (terminals): IP20
• Degree of protection (front): IP40
• Terminal type: Screw terminals
• Terminal capacity (solid/stranded): 1–25 mm²
• Standard compliance: EN 60898-1, IEC 60898-1
• Energy limiting class: 3
• Operating temperature range: -25 °C to +75 °C
• Pollution degree: 2
• Electrical endurance: >10,000 operations
• Mechanical endurance: >20,000 operations
• Module width: 1 (17.5 mm)
• Connection position: Top and bottom
• Type of voltage: AC

Final note

With its proven PXL series design, the Eaton 236055 combines safety, simplicity and long service life. The clearly marked terminals and snap-on DIN rail clip make installation straightforward for electricians and panel builders.
