Finder Relè a stato solido serie 77 ingresso 24V DC 2A 1NO montaggio a innesto 770190249024

Solid state relay with DC switching output, capable of handling up to 2 A at 24 V DC. Opto-isolated input for reliable control signal separation and a green LED status indicator for quick visual confirmation.

Advantages

Instantaneous switching without mechanical wear, long electrical life, and silent operation. Input reverse polarity protection prevents damage from wiring errors. Plug-in design for 97 series sockets simplifies installation and maintenance.

Suitable for

• Industrial automation and control panels
• DC motor and solenoid switching
• Heating and lighting control in DC circuits
• Interface between PLC outputs and DC loads

Key specifications

• Relay type: Solid state relay
• Output type: DC switching
• Control voltage: 24 V DC
• Load voltage: 24 V DC
• Rated output current: 2 A
• Number of poles: 1
• Contact configuration: 1 NO (normally open)
• Switching principle: Instantaneous
• Isolation: Opto-isolation
• Dielectric strength input/output: 2.5 kV AC
• Status indicator: Green LED
• Mounting type: Plug-in (for 97 series sockets)
• Operating temperature range: -20 to +60 °C
• Protection features: Input reverse polarity protection
• Housing material: Plastic
• Series: Finder Series 77

Recommendations

Pair with Finder 97 series sockets for secure mounting and easy wiring. Verify load inductance; consider freewheeling diode for inductive DC loads to protect the SSR output.
