FRAENKISCHE ROHRWERKE GEBR. KIRCHNER GMBH & CO. KG Curva a innesto in alluminio ABS-E 50 (20960050)

90° plug-in bend for cable tray systems, made of aluminium with integrated electrical continuity for protective conductor connection.

Overview

The ABS-E 50 is a 90° bend for cable tray systems, featuring a tool-free plug-in connection. Constructed from aluminium, it offers high corrosion and UV resistance, suitable for both indoor and outdoor use. The bend is designed for horizontal cable routing direction changes and is compatible with OBO Bettermann cable tray systems with a side height of 50 mm. Its inner bend radius is 100 mm.

What stands out

• Tool-free plug-in connection for quick installation
• Aluminium construction provides high corrosion and UV resistance
• Integrated electrical continuity for protective conductor connection
• Complies with DIN EN 61537

Technical details

• Product type: Cable tray bend
• Bend angle: 90°
• Material: Aluminium
• Side height compatibility: 50 mm
• Inner bend radius: 100 mm
• Mounting type: Plug-in
• Surface treatment: Untreated
• Colour: Aluminium (metallic)
• Series: ABS-E
• Fire behaviour: Non-combustible material

Our verdict

A reliable and efficient solution for changing cable tray direction, combining easy installation with durable aluminium construction.
