Fujitsu DX1/200S5 IFCard SAS 2Port 12G x1 (12Gbit/s, SAS, 2port) ETAHA2F-L

The Fujitsu ETAHA2F-L is a high-performance SAS Host Bus Adapter (HBA) designed for integration into Fujitsu PRIMERGY servers. It provides two 12 Gbit/s SAS 3.0 ports via Mini-SAS HD connectors, enabling high-speed connectivity for SAS and SATA storage devices. Based on the Broadcom (LSI) SAS3008 controller in IT mode, this low-profile card supports up to 256 devices through expanders and is ideal for direct-attached storage configurations.

Advantages

This HBA delivers exceptional data transfer rates of up to 12 Gbit/s per port, ensuring rapid access to storage. Its PCI Express 3.0 x8 host interface provides ample bandwidth for demanding workloads. The low-profile form factor with included full-height bracket allows flexible installation in various server chassis. With no hardware RAID overhead, it offers maximum performance and compatibility for HBA-mode deployments.

Suitable for

• Fujitsu PRIMERGY servers requiring SAS/SATA connectivity
• Direct-attached storage (DAS) environments
• High-bandwidth applications such as data analytics, virtualization, and backup
• Integration into existing storage infrastructures

Key specifications

• Product Type: SAS Host Bus Adapter (HBA)
• Host Interface: PCI Express 3.0 x8
• SAS Generation: SAS 3.0 (12 Gbit/s)
• Number of Ports: 2
• Internal Connectors: 2x Mini-SAS HD (SFF-8643)
• Controller Chipset: Broadcom (LSI) SAS3008
• RAID Support: No (HBA mode)
• Supported Devices: SAS HDDs/SSDs, SATA HDDs/SSDs
• Maximum Devices Supported: Up to 256 (via expanders)
• Form Factor: Low Profile (full-height bracket included)
• Operating System Support: Windows Server, Linux, VMware ESXi
• Compatibility: Fujitsu PRIMERGY Servers
• Firmware Type: IT (Initiator Target) Mode
• Board Design: Fujitsu D3307-A12 GS1

Recommendations

For optimal performance, pair this HBA with high-speed SAS SSDs and ensure your server's PCIe slot supports Gen3 x8. Verify compatibility with your specific Fujitsu PRIMERGY model before installation.
