Gira 4458015 presa SCHUKO con stampa sistema EDV, bianco puro lucido

In modern offices and data centers, standard power outlets often lack clear identification for dedicated IT circuits, leading to accidental disconnections. The Gira 4458015 SCHUKO socket outlet with EDV System imprint solves this by providing a dedicated, clearly marked connection point for computers, servers, and network equipment.

Who is it for

This socket is ideal for electricians, IT administrators, and facility managers who need reliable, labeled power outlets for data systems in commercial or residential settings.

Main features

• SCHUKO socket type (Type F) with integrated child protection shutters
• Fixed "EDV System" imprint for easy identification of IT power circuits
• Rated voltage: 250 V AC, rated current: 16 A
• Flush-mounted installation with screw terminals for conductors up to 2.5 mm²
• Compatible with Gira System 55 frames and cover plates
• Halogen-free thermoplastic material in pure white glossy finish

Specifications

• Socket type: SCHUKO
• Imprint: EDV System
• Rated voltage: 250 V AC
• Rated current: 16 A
• Mounting type: Flush-mounted
• Connection type: Screw terminals
• Design line: Gira System 55
• Material: Thermoplastic (halogen-free)
• Colour: Pure white glossy
• Number of sockets: 1
• Child protection: Integrated (shutter)
• Conductor cross-section: Up to 2.5 mm² (rigid)
• Installation depth: Approx. 32 mm

Tips

Pair with a matching Gira System 55 frame and cover plate for a seamless look. Use only with fixed wiring in accordance with DIN VDE 0620-1.
