Gira System 55 Presa SCHUKO con coperchio a ribalta, antracite 418028

In damp rooms or protected outdoor areas, a standard socket outlet can be vulnerable to moisture and dust. The Gira System 55 SCHUKO socket outlet with hinged cover solves this by providing a robust, IP44-rated seal when the cover is closed. Its anthracite finish integrates seamlessly into the Gira System 55 design line, offering both protection and a modern look.

Who is it for

This socket outlet is ideal for electricians, installers, and homeowners who need a reliable, moisture-resistant power point in bathrooms, kitchens, covered terraces, or garages. It suits anyone using the Gira System 55 frame system who values consistent design and safety.

Main features

• SCHUKO socket (Type F) with hinged cover for IP44 protection when closed
• Flush-mounted installation, compatible with Gira System 55, E2, Event, Esprit, and ClassiX frames
• Rated voltage 250 V AC, rated current 16 A
• Thermoplastic (PC) material, halogen-free
• Screw terminals for conductors up to 2.5 mm² rigid
• VDE certified

Specifications

• Socket type: SCHUKO (Type F)
• Number of sockets: 1
• Mounting type: Flush-mounted
• Connection type: Screw terminals
• Rated voltage: 250 V AC
• Rated current: 16 A
• IP rating: IP44 (with hinged cover closed)
• Material: Thermoplastic (PC)
• Halogen-free: Yes
• Colour: Anthracite
• Installation depth: approx. 32 mm
• Compatibility: Gira System 55, E2, Event, Esprit, ClassiX frames
• Application area: Indoor (damp rooms) / Protected outdoor areas
• Certification: VDE

Tips

For optimal protection, ensure the hinged cover is fully closed when the socket is not in use. Pair with a matching Gira System 55 frame in anthracite for a cohesive look. When installing, use rigid conductors up to 2.5 mm² for secure screw terminal connections.
