Grafenthal Cavo patch Cat.6A S/FTP CU LSZH 0,25m verde

The Grafenthal GT6ASFTPL00025GNN is a high-performance Cat.6A S/FTP patch cable designed for reliable 10 Gigabit Ethernet connections. Featuring pure copper conductors and LSZH jacket, it ensures excellent signal integrity and safety in sensitive environments.

Advantages

This cable offers superior shielding against electromagnetic interference (EMI) thanks to its S/FTP construction, making it ideal for data centers and industrial settings. The snagless boot protects the RJ45 connectors during installation, while the LSZH jacket reduces toxic fumes in case of fire.

Suitable for

• Network connections requiring 10GBASE-T performance
• Data centers, server rooms, and office LANs
• Applications where low smoke and zero halogen materials are mandated

Key specifications

• Cable Type: Patch Cable
• Ethernet Category: Cat.6A
• Shielding: S/FTP
• Conductor: Pure Copper (CU)
• Jacket: LSZH (Low Smoke Zero Halogen)
• Length: 0.25 m
• Colour: Green
• Connectors: RJ45 Male to RJ45 Male
• Data Transfer Rate: Up to 10 Gbps
• Bandwidth: Up to 250 MHz
• Wiring Standard: TIA/EIA-568B
• Conductor Gauge: 26 AWG
• Number of Conductors: 8 (4 Twisted Pairs)
• Connector Plating: Gold-plated contacts
• Boot Type: Snagless
• Fire Safety: IEC 60332-1
• Compliance: RoHS, CE

Recommendations

For optimal performance, pair this cable with Cat.6A compatible switches and patch panels. Ensure proper cable management to maintain bend radius and avoid signal degradation.
