Grafenthal Cavo patch Cat6 S/FTP CU - Cavo di rete - 10 Gigabit Ethernet - grigio

The Grafenthal Patch Cable Cat6 S/FTP CU is a high-performance network cable designed for reliable and fast data transmission in professional LAN environments. With its S/FTP shielding and pure copper conductors, this cable ensures minimal interference and supports up to 10 Gigabit Ethernet speeds, making it ideal for data centers, server rooms, and demanding network applications.

Advantages

This cable offers superior signal integrity and protection against electromagnetic interference thanks to its S/FTP (Screened Foiled Twisted Pair) shielding. The 26 AWG stranded copper conductors provide flexibility and durability, while the snagless boot design prevents damage during installation. It is also Power over Ethernet (PoE) compatible, allowing power and data transmission over a single cable.

Suitable for

• Connecting computers, switches, routers, and other network devices in structured cabling systems
• High-speed data transfer in data centers and server rooms
• 10GBASE-T networks requiring Cat6 performance
• PoE applications such as IP cameras, wireless access points, and VoIP phones

Key specifications

• Cable Type: Patch Cable
• Category: Cat6
• Shielding: S/FTP
• Conductor Material: Copper (CU)
• Conductor Type: Stranded
• AWG: 26 AWG
• Jacket Material: PVC
• Connector Type: RJ45 Male to RJ45 Male
• Connector Plating: 50µm Gold-plated contacts
• Wiring Standard: TIA/EIA 568B
• Bandwidth: Up to 250 MHz
• Data Transfer Rate: Up to 10 Gbps
• Colour: Grey
• Outer Diameter: Approx. 6.0 mm
• Operating Temperature: -20°C to 60°C
• Certifications: RoHS, CE
• PoE Support: Yes
• Boot Type: Snagless Boot

Recommendations

For optimal performance, use this cable with Cat6 or higher compatible network equipment. Ensure proper cable management to avoid kinking or sharp bends. This cable is backward compatible with Cat5e and Cat5 networks.
