Hager pulsante 1930/vetro nero WTE5182BG

The Hager WTE5182BG is a high-quality push button switch from the 1930 design series, featuring a sleek black glass front plate with a glossy finish. Designed for momentary operation, this 1-gang switch is ideal for modern flush-mounted installations, combining aesthetic elegance with reliable functionality.

Advantages

This push button offers a premium glass surface that is both UV resistant and halogen-free, ensuring long-lasting durability and safety. The screw terminal connection supports wire sizes from 1.5 to 2.5 mm², providing secure and easy installation. With a rated voltage of 250 V AC and a current of 10 A, it is suitable for a wide range of residential and commercial applications.

Suitable for

• Flush-mounted installations in standard boxes
• Momentary switching applications (e.g., doorbells, call systems)
• Modern interiors requiring a minimalist glass design

Key specifications

• Product Type: Push Button Switch
• Design Series: 1930
• Number of Gangs: 1-gang
• Operation Type: Momentary
• Mounting Type: Flush-mounted
• Material (Front Plate): Glass
• Color: Black
• Surface Finish: Glossy
• Connection Type: Screw Terminals
• Rated Voltage: 250 V AC
• Rated Current: 10 A
• IP Protection Class: IP20
• Halogen-free: Yes
• UV Resistant: Yes
• Backlighting: No
• Terminal Capacity: 1.5 - 2.5 mm²
• Certifications: CE
• Installation Depth (Mechanism): Approx. 21 mm

Recommendations

For a complete and coordinated look, pair this push button with other devices from the Hager 1930 series. Ensure compatibility with standard flush-mounted boxes and follow local electrical codes during installation.
