HAGER WNC126 presa Schuko, 2 moduli, orizzontale, bianco

The HAGER WNC126 stands out with its horizontal double Schuko socket configuration, ideal for installations where vertical space is limited or where a low-profile appearance is preferred. This flush-mount unit combines two earthed Type F outlets in a single frame, delivering a clean and practical power solution for residential and commercial settings.

Highlights

• 2-gang Schuko socket outlet with earthing pin
• Horizontal orientation for space-saving installation
• Increased touch protection (child safety shutters)
• Flush-mount design for seamless integration
• Polar white thermoplastic construction

In daily use

Rated at 250 V AC and 16 A, the WNC126 handles standard household and office loads with ease. Screw terminals accept rigid conductors from 1.5 to 2.5 mm², ensuring a secure and durable connection. The glossy polar white finish complements modern interiors and is compatible with Berker S.1, B.3, and B.7 design frames.

Full specifications

• Socket type: Type F (Schuko)
• Number of sockets: 2
• Orientation: Horizontal
• Rated voltage: 250 V AC
• Rated current: 16 A
• Frequency: 50/60 Hz
• Mounting type: Flush-mount
• Connection type: Screw terminals
• Terminal capacity: 1.5 - 2.5 mm² rigid conductors
• Increased touch protection: Yes (child protection / shutter)
• Material: Thermoplastic (PC)
• Colour: Polar white
• Surface finish: Glossy
• Protection degree: IP20
• Halogen-free: Yes

Final note

A reliable and safe double socket outlet that combines functionality with a sleek, horizontal design.
