Hager WWS1111WP Presa SCHUKO con coperchio a ribalta, da incasso, IP44, bianco

The Hager WWS1111WP is a high-quality SCHUKO (Type F) socket outlet designed for flush-mounted installation. Featuring a hinged lid and IP44 protection, it is ideal for use in damp environments such as bathrooms, kitchens, or outdoor areas. The integrated child protection ensures safe operation, while the matt white finish (RAL 9010) blends seamlessly with modern interiors.

Advantages

This socket offers reliable protection against splash water and dust ingress thanks to its IP44 rating. The hinged lid keeps the socket closed when not in use, preventing accidental contact. The integrated child protection (enhanced touch protection) provides additional safety for households with children. Made from halogen-free thermoplastic, it is environmentally friendly and durable.

Suitable for

• Bathrooms and wet rooms
• Kitchens and utility rooms
• Outdoor areas (under eaves or in sheltered locations)
• Commercial and residential installations requiring IP44 protection

Key specifications

• Socket type: SCHUKO (Type F)
• Number of sockets: 1
• Mounting type: Flush-mounted (UP)
• Protection degree: IP44
• Colour: White (Polarweiß, RAL 9010)
• Rated voltage: 250 V AC
• Rated current: 16 A
• Frequency: 50/60 Hz
• With hinged lid: Yes
• Child protection: Yes (integrated)
• Connection type: Screw terminals
• Material: Thermoplastic, halogen-free
• Impact resistance: IK05
• Terminal capacity (rigid): 1.5 - 2.5 mm²
• Terminal capacity (flexible): 1.5 - 2.5 mm²
• Operating temperature: -5 to 40 °C
• Design line: WG UP
• Surface finish: Matt
• Mounting method: Claw and screw mounting

Recommendations

For optimal protection in damp areas, pair this socket with a suitable flush-mounted box and ensure proper sealing. Always follow local electrical regulations during installation.
