HAGER ZY5R2SI SIBO 1A pacchetto di dotazione per APZ/RfZ, 1400mm, grigio

For electricians equipping a Hager meter cabinet with a smart meter gateway and communication devices, the ZY5R2SI equipment package provides pre-assembled APZ and RfZ modules in a single kit. It fits a 1400 mm installation height and includes one meter place, with 12 TE width for the APZ and 12 TE for the RfZ.

Key specifications

• Product type: Equipment package / assembly kit
• Application: Meter connection point (APZ) and space for additional applications (RfZ)
• Installation height: 1400 mm
• Number of meter places: 1
• APZ module width: 12 TE
• RfZ module width: 12 TE
• Material: Plastic, galvanized steel
• Colour: Grey (RAL 7035)
• Series: SIBO
• Pre-assembled: Yes

Why choose it

The kit is pre-assembled for quick installation, reducing on-site assembly time. It is compatible with Hager ZB and ZS series meter cabinets and meets the requirements of DIN VDE 0603-1 and VDE-AR-N 4100 for modern metering systems.

Ideal use cases

• Equipping meter cabinets in residential or commercial buildings
• Preparing for smart meter gateway installation
• Retrofitting existing Hager cabinets for communication technology

Good to know

The package includes APZ and RfZ modules, a mounting plate for communication devices, DIN rails, terminal blocks, covers, and mounting material. Internal protection class is IP2XC.
