HellermannTyton HTAPE-SHIELD310-EPR-BK nastro isolante EPR autoagglomerante, 19 mm x 4,6 m, nero 711-10000

Self-amalgamating insulating tape made of ethylene propylene rubber (EPR) delivers a moisture-tight, void-free seal for primary electrical insulation up to 69 kV. The tape fuses to itself without adhesive, creating a homogeneous, water-resistant barrier that remains flexible across a wide temperature range.

Advantages

Excellent UV and moisture resistance, high elongation, and self-fusing properties ensure long-term reliability in demanding electrical environments. The tape withstands temperatures from -40°C to +90°C, with emergency overload up to +130°C.

Suitable for

• Cable splicing and repair
• Primary insulation for low and medium voltage applications
• Moisture sealing of connections and terminations

Key specifications

• Tape length: 4.6 m
• Tape width: 19 mm
• Tape thickness: 0.76 mm
• Colour: Black
• Material: Ethylene Propylene Rubber (EPR)
• Dielectric strength: >30 kV/mm
• Elongation at break: >900%
• Tensile strength: >1.7 MPa

Recommendations

For best results, stretch the tape to approximately 75% of its original length while wrapping, overlapping each turn by half the tape width. Ensure the surface is clean and dry before application.
