JULTEC JAD309TSM presa terminale per antenna 3 fori 9dB disaccoppiata a diodi (JAD309TSM)

The JULTEC JAD309TSM is a high-quality antenna end socket designed for single outlet or end-of-line distribution systems. It features three outputs: TV (IEC male), Radio (IEC female), and SAT (F-connector), with 9 dB attenuation on all paths. The SAT output is diode-decoupled from the terrestrial path, ensuring optimal signal isolation. With a frequency range of 5-862 MHz for terrestrial and 950-2200 MHz for satellite, it supports DVB-T/T2, DVB-C, DVB-S/S2, FM, and DAB+.

Advantages

Diode-decoupled SAT output prevents DC interference, while high shielding (>85 dB Class A) ensures minimal signal loss. The flush-mount design integrates seamlessly into walls, and the 75 Ohm impedance matches standard coaxial systems.

Suitable for

• Single outlet TV/Radio/SAT installations
• End-of-line distribution systems
• Residential and commercial antenna systems

Key specifications

• Product Type: Antenna End Socket
• Number of Outputs: 3
• Output Connector TV: IEC Male
• Output Connector Radio: IEC Female
• Output Connector SAT: F-connector
• Connection Attenuation TV/Radio: 9 dB
• Connection Attenuation SAT: 9 dB
• Frequency Range Terrestrial: 5 - 862 MHz
• Frequency Range Satellite: 950 - 2200 MHz
• Return Path Frequency Range: 5 - 65 MHz
• DC Isolation: Diode-decoupled SAT output
• Shielding Factor: > 85 dB (Class A)
• Isolation TV-Radio: > 20 dB
• Isolation TV-SAT: > 20 dB
• Isolation Radio-SAT: > 20 dB
• Impedance: 75 Ohm
• Mounting Type: Flush-mount
• Application: Single outlet / End of line
• Compatibility: DVB-T/T2, DVB-C, DVB-S/S2, FM, DAB+

Recommendations

For best performance, use with high-quality coaxial cables and ensure proper grounding. Ideal for new installations or upgrades.
