Jung presa doppia SCHUKO 16A 250V bianco alpino 8220NAWSL

Electricians and homeowners upgrading residential or commercial installations will find the Jung 8220NAWSL a reliable choice for flush-mounted power distribution. This double SCHUKO socket outlet delivers two independently usable 16 A connections in a single compact unit, ideal for kitchens, offices, and living areas where multiple devices need power from one wall box. The alpine white finish (RAL 9010) blends seamlessly with the Jung AS / A range frames, ensuring a clean, uniform look across the entire electrical installation.

Key specifications

• Socket type: SCHUKO (Type F, CEE 7/3)
• Number of sockets: 2-gang (double)
• Rated current: 16 A
• Rated voltage: 250 V AC, 50/60 Hz
• Mounting type: Flush-mounted (Unterputz)
• Connection type: Screw terminals, up to 2.5 mm² rigid conductors
• Material: Halogen-free thermoplastic (PC/ABS)
• Colour: Alpine white (RAL 9010)
• Protection class: IP20 (indoor use only)
• Operating temperature: -5 °C to +40 °C
• Compatible with Jung AS / A range frames

Why choose it

This outlet combines robust construction with a timeless design. The halogen-free thermoplastic housing meets modern environmental standards, while the screw terminals provide a secure, maintenance-free connection. The double socket configuration doubles the available power points without requiring additional wall boxes, saving installation time and cost. Its IP20 rating is appropriate for dry indoor environments, and the alpine white colour matches standard interior palettes.

Ideal use cases

• Kitchens: power small appliances like kettles and toasters simultaneously
• Home offices: connect a computer and a printer from one location
• Living rooms: supply floor lamps and media devices without extension cords
• Commercial spaces: convenient power access in meeting rooms and workstations

Good to know

The socket does not include increased touch protection (child safety shutters). For installations requiring enhanced safety, consider pairing with appropriate protective accessories. The unit is designed for horizontal or vertical orientation when used with a compatible frame. Always install by a qualified electrician and ensure the circuit is de-energized before work. The product is halogen-free, contributing to lower smoke toxicity in case of fire.
