KATHREIN Euroline KEA 650R parabola satellitare offset 65cm antracite 36dBi 20010049

Offset parabolic satellite dish with 36 dBi gain and 65 cm aluminum reflector for reliable reception across the 10.7–12.75 GHz band. The galvanized steel mast mount and wind resistance up to 200 km/h ensure stable outdoor installation.

Advantages

High efficiency (>70%) and cross-polarization decoupling (>27 dB) deliver clear signal quality. The anthracite finish blends with building exteriors, and the 40 mm LNB holder supports standard LNBs. Mast clamp fits 30–90 mm diameters.

Suitable for

• Satellite TV reception in residential and commercial setups
• Installations requiring a compact yet high-gain dish
• Mast mounting on walls, roofs, or poles

Key specifications

• Antenna type: Offset parabolic dish
• Reflector material: Aluminum
• Mount material: Galvanized steel
• Dish diameter: 65 cm
• Gain: 36 dBi at 11.3 GHz
• Offset angle: 21.5°
• Half-power beamwidth: 2.8°
• Cross-polarization decoupling: >27 dB
• Frequency range: 10.7–12.75 GHz
• LNB holder diameter: 40 mm
• Mast clamp diameter range: 30–90 mm
• Wind load resistance: up to 200 km/h
• F/D ratio: 0.6
• Efficiency: >70%
• Colour: Anthracite

Recommendations

Pair with a universal LNB and a sturdy mast for optimal performance. Ensure clear line of sight to the satellite and use a signal meter for precise alignment.
