KONTAK-SIMON Simon 10 Presa Schuko nero opaco 1 posto con coperchio a ribalta e protezione bambini IP44 morsetti a molla 16A

Exposed to splashes, dust, or curious fingers, standard sockets quickly become a liability. The KONTAK-SIMON Simon 10 socket in matt black tackles all three: a spring-loaded protective flap seals the Schuko outlet when idle, integrated child shutters block foreign objects, and an IP44 rating shrugs off moisture in bathrooms, kitchens, and sheltered outdoor areas.

Who is it for

Electricians and homeowners upgrading damp or dust-prone zones—laundries, covered terraces, workshops, utility rooms. The flush-mounted design suits standard 60 mm wall boxes, while the 10-module format integrates neatly with Simon 10 frames and plates.

Main features

• 1-gang Schuko (Type F, CEE 7/3) socket with earthing contacts
• IP44 protection: hinged flap and sealed housing resist splashing water
• Integrated child shutters prevent accidental contact with live parts
• Spring clamp terminals for fast, tool-free conductor connection
• Rated 16 A / 250 V AC, 50/60 Hz, compliant with EN 60884-1
• Matt black thermoplastic (PC/ABS) faceplate, scratch-resistant and UV-stable
• Flush mounting, 1 module width, approx. 28 mm installation depth

Specifications

• Socket type: Schuko (Type F, CEE 7/3)
• Number of sockets: 1
• Rated current: 16 A
• Rated voltage: 250 V AC
• Frequency: 50/60 Hz
• Connection: spring clamps (quick connection)
• Material: thermoplastic (PC/ABS)
• Colour: matt black
• IP rating: IP44
• Mounting: flush-mounted
• Module size: 1 module
• Installation depth: approx. 28 mm
• Operating temperature: -5°C to +35°C
• Standards: CE, EN 60884-1

Tips

Pair with a Simon 10 matt black frame and cover plate for a seamless look. For outdoor use, ensure the socket is installed under a canopy or in a weatherproof enclosure to maintain IP44 performance. Spring clamps accept solid or stranded conductors up to 2.5 mm² without ferrules.
