MEAN WELL IRM-20-15 - Alimentatore incapsulato per montaggio su PCB 20W 15V 1,34A, ingresso 85-264VAC, nero

With an impressive 88% efficiency and a wide 85-264VAC input range, the MEAN WELL IRM-20-15 delivers reliable 20W power in a compact, PCB-mountable module. This enclosed power supply outputs 15VDC at 1.34A, making it an ideal choice for industrial electronics, automation systems, and ITE applications requiring stable DC power.

Overview

The IRM-20-15 is a 20W AC/DC power module from MEAN WELL's IRM-20 series, designed for direct PCB mounting. It accepts universal AC input (85-264VAC) and provides a regulated 15V DC output. The unit features a fully enclosed plastic case, free air convection cooling, and a wide operating temperature range from -30°C to +70°C. Safety certified to UL60950-1, TUV EN60950-1, and EAC TP TC 004, it meets international standards for ITE equipment.

What stands out

• High efficiency up to 88% reduces energy waste and heat generation.
• Ultra-low no-load power consumption (<0.1W) meets energy-saving regulations.
• Comprehensive protection: short circuit, overload, and over voltage.
• Compact dimensions (52.4mm L x 27.2mm W x 24mm H) save board space.
• Wide operating temperature range (-30°C to +70°C) for harsh environments.
• 3kVAC isolation voltage ensures safety between input and output.

Technical details

• Output Power: 20W
• Output Voltage: 15VDC
• Output Current: 1.34A
• Input Voltage: 85-264VAC (120-370VDC)
• Input Frequency: 47-440Hz
• Ripple & Noise: 150mVp-p
• Isolation Voltage: 3kVAC
• MTBF: >700k hours (MIL-HDBK-217F)
• Safety Standards: UL60950-1, TUV EN60950-1, EAC TP TC 004
• Compliance: RoHS
• Color: Black

Our verdict

The MEAN WELL IRM-20-15 is a robust and efficient power solution for PCB integration. Its high efficiency, low standby power, and comprehensive protections make it a dependable choice for engineers and designers seeking a compact, certified power module.
