METZ BTR 130861-MSK-E Kit di espansione per cassette di giunzione in fibra ottica per contenitore modulare AP

For network technicians and installers working with BTR Netcom modular AP housings, the METZ BTR 130861-MSK-E fiber optic splice cassette expansion set provides a reliable solution for managing fusion splices in fiber optic networks. This set includes a splice cassette, 12 crimp splice protectors, and cable ties, enabling secure fiber splicing and strain relief within the housing.

Key specifications

• Splice capacity: up to 12 fusion splices
• Compatibility: BTR Netcom Modul AP-Gehäuse (Modular AP Housing)
• Material: Plastic
• Colour: Black
• Operating temperature: -20°C to +70°C
• Storage temperature: -40°C to +85°C
• Compliance: RoHS, REACH

Why choose it

The cassette integrates seamlessly into the modular housing, offering organized fiber management and protection for splices. Its clip-in/screw-in mounting ensures a stable installation, while the included crimp protectors and cable ties facilitate neat and secure cable routing.

Ideal use cases

• Fiber optic splicing in indoor network distribution points
• Expanding splice capacity in existing modular AP housings
• Organizing and protecting fusion splices in multimode or singlemode installations

Good to know

Designed for indoor use, this expansion set is a practical addition to BTR Netcom infrastructure, supporting both multimode and singlemode fibers. The cassette itself has no direct cable entry; cable management is handled through the housing design.
