METZ CONNECT cavo patch SC/APC OS2 monomodale, verde, 2 m, confezione da 20

The METZ CONNECT 1509QAEA002C-E is a high-quality SC/APC to SC/APC simplex patch cable designed for single-mode OS2 fiber networks. With a 2-meter length and a vibrant green LSZH jacket, this cable ensures reliable, low-loss connections in data centers, FTTx, telecommunications, and LAN environments. Each pack contains 20 pieces, making it ideal for bulk installations.

Advantages

Engineered with premium zirconia ceramic ferrules and APC polishing, this patch cable delivers exceptional insertion loss (≤0.3 dB) and return loss (≥60 dB), ensuring minimal signal degradation. The G.657.A1 fiber standard provides excellent bend performance with a minimum bend radius of just 10 mm, simplifying installation in tight spaces. The LSZH jacket enhances safety by reducing toxic smoke and halogen emissions in case of fire.

Suitable for

• Data center structured cabling
• FTTx (Fiber to the x) deployments
• Telecommunications networks
• Local area networks (LAN)
• High-speed single-mode fiber links

Key specifications

• Connector Type: SC/APC
• Fiber Type: OS2 Single-mode
• Fiber Standard: G.657.A1
• Core/Cladding Diameter: 9/125 µm
• Cable Length: 2 m
• Jacket Color: Green
• Quantity per Pack: 20 pieces
• Insertion Loss (typical): ≤ 0.3 dB
• Return Loss (typical): ≥ 60 dB
• Ferrule Material: Zirconia Ceramic
• Cable Jacket Material: LSZH (Low Smoke Zero Halogen)
• Polishing Type: APC (Angled Physical Contact)
• Cable Construction: Simplex
• Minimum Bend Radius: 10 mm
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Compliance: RoHS, REACH

Recommendations

For optimal performance, ensure proper cleaning of connectors before mating. This cable is compatible with standard SC/APC adapters and equipment. Store in a clean, dry environment within the specified temperature range.
