Miboxer pannello touch LED Smart DALI 3 in 1 DT8 (DP3S)

The Miboxer DP3S is a premium DALI-2 touch panel controller designed for professional lighting control. It integrates three control modes—single color, CCT, and RGB/RGBW/RGB+CCT (DT8)—into a sleek wall-mounted unit. With a tempered glass surface and capacitive touch interface, it offers intuitive operation for dimming, color selection, and scene recall. Built-in DALI bus power supply (100mA) simplifies installation, making it ideal for modern smart lighting systems.

Advantages

• Supports DALI-2 DT6 and DT8 device types for versatile control.
• Built-in DALI bus power supply eliminates need for external PSU.
• Capacitive touch panel with tempered glass for durability and style.
• Wide dimming range (0.1%–100%) and color temperature adjustment (2700K–6500K).
• Low standby power consumption (<0.5W) for energy efficiency.

Suitable for

• Residential smart lighting systems
• Commercial offices and meeting rooms
• Retail and hospitality environments
• Any DALI-2 compatible lighting installation

Key specifications

• Control Protocol: DALI-2 (IEC 62386)
• DALI Device Type Support: DT6 (Single Color, CCT), DT8 (RGB, RGBW, RGB+CCT)
• Input Voltage: AC 100-240V, 50/60Hz
• Output Signal: DALI Bus
• DALI Bus Power Supply: Built-in, 100mA
• Control Zones: 1 Zone
• Installation Type: Wall-mounted (Standard 86-type junction box)
• Panel Material: Tempered Glass
• Control Method: Capacitive Touch Panel
• Dimming Range: 0.1% - 100%
• Color Temperature Range: 2700K - 6500K
• Operating Temperature: -10°C to 40°C
• Relative Humidity: 20% - 80% (non-condensing)
• Standby Power Consumption: <0.5W
• Protection Rating: IP20
• Certifications: CE, RoHS
• Compatibility: DALI-2 certified devices, Miboxer DALI series drivers

Recommendations

For optimal performance, pair with Miboxer DALI series LED drivers. Ensure DALI bus wiring complies with IEC 62386 standards. Suitable for indoor use only.
