Miboxer Synergy 21 Telecomando LED 2,4 GHz 4 zone Wireless Dimming Panel (K4-B)

The Miboxer Synergy 21 K4-B is a high-quality 2.4GHz wireless RF touch panel remote control designed for LED lighting systems. It allows you to control up to 4 independent zones with smooth dimming and color temperature adjustment (for CCT compatible lights). The sleek white tempered glass panel fits standard 86-type wall boxes, providing a modern and intuitive interface for your smart lighting.

Advantages

Enjoy precise control over your LED lights with a high-precision capacitive touch panel. The remote offers 0-100% dimming range, on/off control, and color temperature adjustment for compatible lights. With a control distance of up to 30 meters in open areas, you can manage your lighting from anywhere in the room. The low standby power consumption (<0.1W) ensures energy efficiency.

Suitable for

• Residential and commercial LED lighting systems
• Compatible with Mi-Light / Miboxer 2.4GHz series LED controllers and receivers
• Ideal for controlling multiple lighting zones independently

Key specifications

• Control Type: Wireless RF Touch Panel
• Wireless Frequency: 2.4GHz
• Number of Control Zones: 4 independent zones
• Control Functions: Brightness Dimming, On/Off, Color Temperature Adjustment (for CCT compatible lights)
• Dimming Range: 0-100%
• Power Supply: AC 100-240V, 50/60Hz
• Installation Type: Wall-mounted (standard 86-type wall box)
• Communication Protocol: 2.4GHz RF
• Control Distance: Up to 30 meters (open area)
• Panel Material: Tempered Glass, PC Plastic
• Operating Temperature: -20°C to 60°C
• Standby Power Consumption: <0.1W
• Control Method: High-precision Capacitive Touch
• Output Signal: 2.4GHz RF
• Compatibility: Mi-Light / Miboxer 2.4GHz series LED controllers/receivers
• Panel Color: White
• Number of Channels: 4
• Certifications: CE, RoHS

Recommendations

For optimal performance, use with Miboxer or Mi-Light 2.4GHz compatible LED controllers. Ensure proper installation in a standard 86mm wall box. This remote is not a standalone device; it requires compatible receivers.
