MITON MT-P1280-B contenitore elettrico, grigio, ABS, IP65, 120x80x70mm

The MITON MT-P1280-B is a robust and reliable electrical enclosure designed for surface mounting. Manufactured from high-quality ABS (Acrylonitrile Butadiene Styrene), this enclosure offers excellent durability and protection for a wide range of electrical and electronic components. With an IP65 rating, it is dust-tight and protected against water jets, making it suitable for both indoor and outdoor applications. The IK07 impact rating ensures resistance against mechanical impacts. The enclosure features an opaque lid secured with four plastic screws, providing secure closure. It is supplied undrilled, allowing for custom gland entries and cable management. The integrated polyurethane gasket ensures a reliable seal. Internal mounting bosses accommodate DIN rails or mounting plates for flexible component installation. Operating temperature range from -25°C to +60°C and UL94-HB flammability rating ensure safe operation in various environments. RoHS compliant.

Advantages

High protection class IP65 and IK07 for demanding environments. Durable ABS material with excellent chemical and UV resistance. Flexible customization with undrilled gland entries. Easy installation with surface-mount design and internal mounting options. Compact size ideal for junction boxes, control housings, and component protection.

Suitable for

• Junction boxes for electrical connections
• Control housings for automation systems
• Component protection in industrial and commercial settings
• Outdoor installations requiring weatherproof protection

Key specifications

• Product Type: Electrical Enclosure
• Mounting Type: Surface-Mounted
• Enclosure Material: ABS (Acrylonitrile Butadiene Styrene)
• Colour: Grey (RAL 7035)
• External Dimensions: 120 x 80 x 70 mm (L x W x H)
• Ingress Protection: IP65
• Impact Protection: IK07
• Lid Type: Opaque
• Lid Fastening: 4x Plastic Screws
• Operating Temperature: -25°C to +60°C
• Flammability Rating: UL94-HB
• Internal Mounting: Mounting bosses for DIN rail or mounting plate
• Gland Entries: Undrilled (user-configurable)
• Seal Material: Polyurethane (PU) Gasket
• Standards: RoHS Compliant

Recommendations

For optimal installation, use appropriate cable glands and mounting accessories. Ensure the enclosure is securely fixed to a stable surface. Customize gland entries as needed for your application. This enclosure is ideal for protecting sensitive electronics in harsh environments.
