KIT DI INSTALLAZIONE FISSA CON CONNETTORE MOLEX DA 6 POLI A 6 POLI C

For fixed installations where a reliable, straight-through 6-pin Molex link is non-negotiable, the Newland NLS-DCC-CCMT93-01 delivers a purpose-built interconnect that removes guesswork from power and signal routing. Unlike generic jumper assemblies that rely on mismatched pinouts or flimsy conductors, this kit pairs a molded 1-meter cable with robust Molex Mini-Fit Jr. compatible connectors on both ends, ensuring a clean 1:1 mapping from source to load.

Highlights

• Molex 6-pin male connectors on both ends for direct, tool-free mating with compatible headers.
• 18 AWG tinned copper conductors rated for 7 A per pin, supporting power and low-speed signal in one run.
• PVC jacket with 300 V rating and -20 °C to +85 °C operating range for indoor fixed installations.
• Straight-through pin configuration eliminates rewiring errors during integration.
• RoHS compliant, black finish, and compact 1 m length suited to control cabinets and device bays.

In daily use

Technicians and system builders will appreciate the kit's plug-and-play nature: both connectors are keyed and polarized, so orientation mistakes are avoided at the physical layer. The 18 AWG tinned copper strands resist corrosion and maintain conductivity over repeated thermal cycles, while the PVC jacket provides abrasion resistance in cable trays or behind panels. Because the assembly is rated for 300 V and 7 A per pin, it can confidently carry moderate power for sensors, actuators, or internal device interconnects without adding a second cable run.

Full specifications

• Connector type (end 1): Molex 6-pin male, Mini-Fit Jr. compatible
• Connector type (end 2): Molex 6-pin male, Mini-Fit Jr. compatible
• Number of pins: 6
• Pin configuration: straight-through (1:1)
• Cable length: 1 m (3.3 ft)
• Wire gauge: 18 AWG
• Conductor material: tinned copper
• Jacket material: PVC (polyvinyl chloride)
• Voltage rating: 300 V
• Current rating per pin: 7 A
• Operating temperature: -20 °C to +85 °C
• Colour: black
• Environmental compliance: RoHS compliant
• Application: fixed installation, power and signal interconnect

Final note

When your build demands a dependable Molex-to-Molex link without custom crimping or adapters, the Newland NLS-DCC-CCMT93-01 keeps the connection simple, safe, and service-ready.
