Patch panel 1U Lanview LVO231517 SC/LC fibra ottica acciaio nero

The Lanview LVO231517 is a 19" 1U fiber patch panel in black steel, designed to organize and protect fiber optic terminations. It accepts up to 24 SC simplex or LC duplex adapters and includes mounting fixtures for splice cassettes and cable management cutouts to secure cables with ties or Velcro, helping to relieve cable stress. The rear panel provides four Ø18 mm circular inlets suitable for PG screw connections and two rectangular inlets measuring 105 x 20 mm.

Advantages

This 1U patch panel offers flexible adapter support for SC and LC connections, durable steel construction for rack environments, and integrated features for splice cassette installation and cable strain relief. The combination of multiple inlet types on the back improves cable entry options during installation.

Suitable for

• Rack-mounted fiber distribution in server rooms and data centers
• Telecommunications equipment cabinets
• FTTx and backbone fiber installations requiring SC or LC connections
• Environments needing organized splice cassette and cable management

Key specifications

• Form factor: 19" 1U
• Maximum adapters: 24 (SC simplex or LC duplex)
• Material: steel
• Colour: black
• Back inlets: 4 × Ø18 mm (PG screw compatible) and 2 × 105 × 20 mm rectangular
• Weight: 3.29 kg

How to use

Install the patch panel into a standard 19" rack at the desired 1U position using appropriate rack screws. Mount splice cassettes into the provided fixtures if splicing is required. Fit SC or LC adapters into the front panel openings and route fiber cables through the chosen back inlets. Secure the cables to the cable management cutouts using cable ties or Velcro straps to maintain bend radius and reduce mechanical stress on terminations.

Recommendations

Handle fibers with care during insertion and routing; maintain proper bend radius and avoid sharp bends. Use the rectangular or circular inlets according to cable diameter and gland requirements, and ensure PG screw fittings are correctly tightened when used. Regularly inspect cable securing points to prevent strain on connectors.
