Piastra separatrice WAGO 283-402 - grigio - larghezza 1,5 mm - per morsetti serie 283

The WAGO 283-402 Partition Plate is a high-quality accessory designed for use with WAGO 283 Series terminal blocks. It provides reliable electrical isolation between adjacent terminal blocks, ensuring safety and preventing short circuits in industrial control panels, building installations, and electrical systems. Made from durable Polyamide 66 (PA 66) with a UL94 V-0 flammability rating, this partition plate offers excellent thermal and mechanical resistance. Its snap-on mounting allows for quick and easy installation without tools. The grey color ensures clear identification and compatibility with standard industrial environments.

Advantages

• Ensures safe electrical isolation between terminal blocks
• Easy snap-on installation saves time and effort
• High-quality PA 66 material with UL94 V-0 rating for fire safety
• Compact 1.5 mm width saves space on DIN rails
• RoHS and REACH compliant for environmental safety

Suitable for

• Industrial control panels
• Building electrical installations
• Automation systems
• Power distribution units

Key specifications

• Product Type: Partition Plate
• Compatibility: WAGO 283 Series Terminal Blocks
• Color: Grey
• Material: Polyamide 66 (PA 66)
• Flammability Rating: UL94 V-0
• Mounting Type: Snap-on
• Function: Electrical Isolation
• Operating Temperature Range: -35 °C to +105 °C
• Storage Temperature Range: -35 °C to +105 °C
• Pollution Degree: 3
• Insulation Material Group: I (IEC 60664)
• Width (Thickness): 1.5 mm
• Height: 38.5 mm
• Depth: 46.5 mm
• RoHS Compliance: Yes
• REACH Compliance: Yes

Recommendations

For optimal performance and safety, use the WAGO 283-402 Partition Plate with genuine WAGO 283 Series terminal blocks. Always follow local electrical codes and regulations during installation.
