Presa NRGkick NRGkick presa a muro 32A nero fusibile 32A

NRGkick wall socket 32A with proprietary interface provides a permanently installed connection point for NRGkick charging units. Rated for a maximum of 32 A/22 kW, the socket serves as an interface to the NRGkick charging unit and is supplied as a single wall-mounted socket designed for building installations where freely accessible CEE sockets are not desired.

Advantages

The NRGkick wall socket uses a proprietary connection interface to prevent unintended devices from being plugged in. It offers smooth connection and disconnection thanks to high-quality contact materials, integrated temperature monitoring on each phase pin, and automatic overheating protection that lets the charging unit independently regulate current if the socket becomes too hot. The design also prevents arcing by interrupting current flow before contacts separate and detects wrongly wired sockets to stop unsafe charging. An additional LED on the Connector Unit communicates status information, and the connector provides secure engagement with easy unplugging when needed. The socket is automatically recognised by the NRGkick charging unit so charging current never exceeds the socket’s approved value.

Suitable for

• Permanent building installations where CEE sockets are not suitable
• Creating multiple low-cost charging points for NRGkick charging units
• Charging electric vehicles with NRGkick charging units

Key specifications

• Rated current: up to 32 A (maximum charging current up to 16 A per phase depending on configuration) — up to 22 kW
• Interface: proprietary NRGkick connection (no external devices supported)
• Protection features: temperature monitoring per phase, overheating protection, automatic hot-unplug detection (prevents arcing), wrong-wiring detection
• Indicator: additional LED on Connector Unit for status
• Mounting: permanently installed wall socket for supply line
• Manufacturer MPN: 20001015, EAN: 9120075710749

How to use

Install the NRGkick wall socket permanently on the supply line as part of the building’s electrical installation. When you need to charge an electric vehicle, connect the NRGkick charging unit’s Connector Unit to the wall socket; the connector engages securely and the additional LED indicates the unit’s status. The NRGkick charging unit will automatically identify the socket and regulate the charging current according to the socket’s approval. If the socket becomes too hot or wiring is incorrect, the charging unit will limit or stop charging and notify via LED.

Recommendations

Use the NRGkick wall socket exclusively with compatible NRGkick charging units. Have the socket installed and inspected by a qualified electrician to ensure correct wiring and safe operation. Observe local electrical codes and the NRGkick charging unit instructions for optimal performance.
