PULS YR40.242 modulo di ridondanza DIN rail 40A 9-30VDC 2 ingressi 1 uscita

Handle up to 40 A output current with a maximum voltage drop of just 0.4 V using the PULS YR40.242 DIN-rail redundancy module. This diode-based decoupling unit accepts two independent 24 VDC power supplies and combines them into a single output, enabling N+1 or N+M redundancy for critical loads.

Overview

The YR40.242 is designed for 24 VDC systems and supports an input voltage range of 9–30 VDC. It features two inputs and one output, with screw terminals for secure wiring. The module mounts on a standard 35 mm DIN rail and operates in temperatures from -25 °C to +70 °C.

What stands out

• High current capacity: 40 A output with low voltage drop
• Dual input for redundant power supply configurations
• Reverse polarity protection on inputs
• Compact metal housing for durability
• Wide operating temperature range

Technical details

• Input voltage range: 9–30 VDC
• Nominal input voltage: 24 VDC
• Output current (max): 40 A
• Number of inputs: 2
• Number of outputs: 1
• Voltage drop: max 0.4 V at 40 A
• Power loss: 16 W at 40 A output
• Mounting: DIN rail (35 mm)
• Operating temperature: -25 °C to +70 °C
• Storage temperature: -40 °C to +85 °C
• Connection: screw terminals
• Housing material: metal (aluminium)

Our verdict

A robust redundancy module for industrial 24 VDC systems, delivering high current with minimal losses and reliable decoupling.
