Telegärtner J60026A0000 TOC M12 connettore maschio da campo schermato 4 poli codifica D, acciaio inox, morsetto a vite, IP68

Industrial automation technicians and field engineers rely on the Telegärtner J60026A0000 TOC plug for robust Ethernet connectivity in harsh environments. This M12 D-coded connector is designed for field assembly, allowing on-site termination of cables with diameters from 4.0 to 8.0 mm. Its stainless steel housing and screw terminal contacts ensure a secure, durable connection for PROFINET and other industrial Ethernet applications.

Key specifications

• Connector type: M12 plug, D-coded, 4-pole
• Shielding: Shielded
• Assembly type: Field assembly
• Housing material: Stainless steel
• Ingress protection: IP68 (when mated)
• Operating temperature range: -40°C to +85°C
• Rated voltage: 250 V AC/DC
• Rated current: 4 A
• Contact plating: Gold over copper alloy
• Insulation resistance: > 10^8 Ω
• Mating cycles: > 100
• Cable diameter range: 4.0 - 8.0 mm
• Connection method: Screw terminal
• Standard compliance: IEC 61076-2-101

Why choose it

The TOC plug offers a reliable, field-terminable solution for industrial networks. Its stainless steel construction withstands demanding conditions, and the screw terminals allow quick, tool-friendly installation without specialized crimping equipment.

Ideal use cases

• Industrial Ethernet and PROFINET installations
• Connecting sensors and actuators in manufacturing plants
• Outdoor or washdown environments requiring IP68 protection

Good to know

This connector is part of the Telegärtner Outdoor Connector (TOC) series, engineered for robust performance in industrial automation.
