TRYTYT puntalino gemello isolato 2x6 mm² giallo (100 pz.) DUID-2X6,0-14ZO

The TRYTYT DUID-2X6,0-14ZO is a high-quality insulated twin bootlace ferrule designed for reliable termination of stranded wires in screw terminals. With a wire cross-section of 2 x 6 mm² and a yellow insulation color, this ferrule ensures secure connections and easy identification. Supplied in a pack of 100 pieces, it meets DIN 46228 Part 4 standards and is suitable for a wide range of electrical applications.

Advantages

Made from tin-plated electrolytic copper with polypropylene insulation, this ferrule offers excellent conductivity, corrosion resistance, and durability. The twin design allows simultaneous termination of two wires, saving time and ensuring consistent contact. The insulation collar provides strain relief and prevents short circuits.

Suitable for

• Termination of stranded wires in screw terminals
• Industrial control panels, switchgear, and distribution boards
• Electrical installations requiring reliable and secure connections
• Automation and machinery wiring

Key specifications

• Product Type: Insulated Twin Bootlace Ferrule
• Wire Cross-Sectional Area: 2 x 6 mm²
• Insulation Color: Yellow
• Pack Quantity: 100 pieces
• Conductor Material: Electrolytic Copper, Tin-plated
• Insulation Material: Polypropylene (PP)
• Metal Part Length (L): 14 mm
• Total Length (L2): 22 mm
• Inner Diameter (D1): 4.9 mm
• Outer Diameter (D2): 5.5 mm
• Insulation Collar Diameter (D3): 8.0 mm
• Standard Compliance: DIN 46228 Part 4
• Temperature Range: -40°C to +105°C
• Voltage Rating: 300V / 600V
• Flammability Rating: UL94 V-2
• Number of Wires per Ferrule: 2

Recommendations

For best results, use with a suitable crimping tool designed for twin ferrules. Ensure wires are stripped to the correct length before insertion. Always follow local electrical codes and manufacturer instructions.
