Victron Energy Orion 12/24-8 convertitore DC-DC 24V 8A ORI122408020

The Victron Energy Orion 12/24-8 is a non-isolated DC-DC converter that steps up 12V input to a regulated 24V output with a continuous current of 8A. Its wide input voltage range (9-18V) and adjustable output (20-30V) make it ideal for charging 24V batteries from a 12V alternator or starter battery in vehicles and boats.

Advantages

The Orion 12/24-8 delivers high efficiency (~92%) and reliable performance in a compact, rugged aluminum enclosure. With remote on/off capability and comprehensive protection against short circuit, over-temperature, and input over/under voltage, it ensures safe operation in demanding environments. Convection cooling and an IP43 rating (when mounted vertically) add to its durability.

Suitable for

• Charging 24V auxiliary batteries from a 12V vehicle system
• Powering 24V equipment in trucks, buses, and marine applications
• DC-DC conversion in off-grid solar and backup power systems

Key specifications

• Input voltage: 9-18V DC (nominal 12V)
• Output voltage: 20-30V DC adjustable (nominal 24V)
• Output current: 8A continuous
• Output power: 192W
• Efficiency: ~92%
• Isolation: Non-isolated
• Remote on/off: Yes
• Operating temperature: -20 to +50°C (full load)
• Protection: Short circuit, over temperature, input over/under voltage
• Connection: Screw terminals
• Enclosure: Aluminum, IP43 (vertical mounting)
• Cooling: Convection
• Standby current: <15mA
• Mounting: Surface mount (4 screw holes)

Recommendations

For reliable 12V to 24V conversion in automotive and marine environments, the Victron Orion 12/24-8 is an excellent choice. Its adjustable output and robust protection features ensure compatibility and longevity. Always verify your system's voltage and current requirements before installation.
