Wirewin cavo patch slim Cat.6A U/UTP 10G, RJ45, 10 m, blu SLIM-L-UU-K6A 10.0 BL

This Cat.6A slim patch cable delivers 10 Gigabit Ethernet with a 500 MHz bandwidth and a narrow 3.6 mm diameter for high-density installations. The U/UTP design with stranded AWG 30/7 copper conductors and gold-plated RJ45 connectors ensures reliable performance in a flexible, LSZH-jacketed form.

Overview

The SLIM WIREWINE SLIM-L-UU-K6A 10.0 BL is a 10-meter unshielded patch cable built for 10GBASE-T networks. Its slim round profile reduces cable bulk in racks and cable managers, while the LSZH jacket meets low-smoke, zero-halogen requirements for safer indoor use.

What stands out

• 10 Gigabit Ethernet support with 500 MHz bandwidth
• Ultra-slim 3.6 mm diameter saves space in dense patching areas
• Stranded AWG 30/7 copper conductors for flexibility
• Gold-plated RJ45 connectors (50 µm) for reliable contact
• LSZH jacket for low smoke and zero halogen emissions
• Supports PoE, PoE+, and 4PPoE (IEEE 802.3af/at/bt)

Technical details

• Cable type: Cat.6A (Class EA) patch cable
• Shielding: U/UTP (unshielded)
• Length: 10.0 m
• Diameter: 3.6 mm
• Conductor: Copper, AWG 30/7 stranded
• Wiring: TIA/EIA 568B
• Connectors: RJ45 male to RJ45 male
• Operating temperature: -20°C to +60°C

Our verdict

A dependable slim Cat.6A cable for high-speed networking in space-constrained environments, with solid construction and safety-focused jacket material.
