Alcatel-Lucent cavo Direct Attach 100GBase QSFP28 su QSFP28 5 m

100 Gigabit Ethernet over passive copper twinax, 5 meters, QSFP28 to QSFP28.

Overview

The Alcatel-Lucent QSFP-100G-C5M is a 5-meter direct attach cable (DAC) for 100GbE links. It uses passive copper twinax with QSFP28 connectors on both ends, compliant with IEEE 802.3bj (100GBASE-CR4) and SFF-8665. The cable is hot-swappable and consumes less than 0.5W per end.

What stands out

• 100Gbps data rate for high-density data center interconnects
• Passive design: no power required for signal conditioning, ultra-low latency
• 26 AWG twinax construction with PVC jacket for durability
• Hot-swappable QSFP28 connectors for easy installation and maintenance
• Operating temperature range 0°C to 70°C

Technical details

• Connector type: QSFP28 to QSFP28
• Cable length: 5 m (16.4 ft)
• Cable technology: Passive copper twinax
• Wire gauge: 26 AWG
• Impedance: 100 Ohm
• Electrical interface: CAUI-4
• Voltage: 3.3V
• Power consumption: < 0.5W per end (typical)
• Operating temperature: 0°C to 70°C
• Storage temperature: -40°C to 85°C
• Jacket material: PVC
• Protocol support: IEEE 802.3bj (100GBASE-CR4), SFF-8665
• Compliance: RoHS, CE, FCC

Our verdict

A reliable 5m passive DAC for 100GbE connections, ideal for rack-to-rack or server-to-switch links in Alcatel-Lucent Enterprise environments and other QSFP28-compliant equipment.
