B-TECH BT8390-VESA200T/B Barre di montaggio - 70 kg (coppia) nero

The B-TECH BT8390-VESA200T/B Mounting Rails are high-grade steel rails designed for professional videowall installations. Supplied as a pair, these 2-meter rails offer a maximum load capacity of 70 kg per rail, making them ideal for supporting large displays in commercial environments. Part of the BT8390 system, they integrate seamlessly with B-TECH's 'pop-out' mounting system for easy maintenance and access.

Advantages

These mounting rails provide a robust and versatile foundation for custom videowall configurations. The powder-coated finish ensures durability and a sleek black appearance. With a rail profile of 40 x 25 mm, they offer excellent strength-to-weight ratio. The pair allows for horizontal or vertical orientation, giving installers flexibility.

Suitable for

• Professional videowall installations in control rooms, digital signage, and broadcast studios
• Mounting flat screen displays using VESA 200 patterns
• Integration with B-TECH BT8390 mounting systems

Key specifications

• Product Type: Mounting Rails
• Quantity: 2 (Pair)
• Rail Length: 2000 mm (2m)
• Rail Profile Dimensions (W x H): 40 x 25 mm
• Material: High-grade Steel
• Colour: Black
• Max Load Capacity (per rail): 70 kg
• Compatibility: B-Tech BT8390 Videowall Mounting Systems
• Application: Professional Videowall Installations
• Mounting Orientation: Horizontal or Vertical (as part of system)
• Finish: Powder Coated
• System Integration: Designed for use with B-Tech's 'pop-out' mounting system
• Installation Type: Wall-mounted (as part of a larger system)
• Model Series: BT8390
• Product Weight (per rail): Approx. 5.25 kg
• Included Components: 2 x Mounting Rails
• Required For: Building custom videowall configurations

Recommendations

For optimal performance, pair these rails with B-TECH BT8390 brackets and ensure proper wall anchoring. Always adhere to safety guidelines and load limits.
