BlueOptics NVIDIA MC2207130-003 cavo DAC QSFP BlueLAN compatibile 56G passivo twinassiale in rame 3m

The BlueOptics NVIDIA MC2207130-003 compatible BlueLAN QSFP Direct Attach Cable (DAC) is a high-performance, passive twinaxial copper cable designed for 56 Gigabit InfiniBand FDR applications. It provides a reliable and cost-effective solution for short-range interconnects within racks and between adjacent racks in data centers.

Advantages

This passive DAC cable offers low power consumption (<0.5W typical), hot-pluggable convenience, and excellent signal integrity for high-speed data transmission. Its twinaxial copper construction ensures durability and flexibility, making it ideal for dense cabling environments.

Suitable for

• High-speed data center interconnects
• Rack-to-rack connections
• Switch-to-server and switch-to-switch links
• InfiniBand FDR networks

Key specifications

• Cable Type: Direct Attach Cable (DAC)
• Data Rate: 56 Gbps
• Connector Type: QSFP to QSFP
• Active/Passive: Passive
• Length: 3 meters
• Impedance: 100 Ohm
• Jacket Material: PVC
• Compliance: RoHS, CE, FCC

Recommendations

For optimal performance, ensure that both connected devices support QSFP interfaces and InfiniBand FDR protocol. This cable is fully compatible with NVIDIA MC2207130-003 and similar equipment.
