Cavo DAC SFP28 BlueOptics SFP28-DAC-0.5M-BL 0,5 m connettore SFP28

The BlueOptics SFP28-DAC-0.5M-BL is a 0.5 m direct attach cable (DAC) with SFP28 connectors designed for short-distance, high-speed interconnects in data centers and network racks. This passive twinax copper cable supports 25GBase-CR class electrical links and is intended for connecting compatible switches, routers, storage systems and other hardware that accept SFP28 DAC modules. The product combines a compact 0.5 m length with SFP28-to-SFP28 connectivity and a lightweight construction for rack-to-rack or in-rack cabling.

Advantages

The cable offers a low-latency, low-power solution for 25 Gbps links with simple passive operation, reducing power consumption compared to active optical modules. Its short length and twinax copper design deliver consistent electrical signal transmission for supported protocols while minimizing latency and insertion loss. The cable is built using MSA-compliant SFP28 connectors and materials suitable for professional installations, providing a reliable lifetime for repeated plug cycles and stable connectivity in dense rack environments.

Suitable for

• Short-distance links inside racks or between adjacent racks
• 25 Gbps Ethernet connections (25GBase-CR)
• FCoE, Fibre Channel and InfiniBand applications up to 25 Gbps
• High-density switch-to-switch or switch-to-server cabling

Key specifications

• Cable length: 0.5 m
• Connector type: SFP28 to SFP28
• Supported data rate: up to 25 Gbps (per supported standard)
• Cable type: passive twinax copper (30 AWG)
• Typical power consumption: passive (near 0.1 W for comparable passive DACs)
• Colour: black and silver exterior elements
• Weight: approximately 0.08 kg

How to use

Ensure both port endpoints officially support passive SFP28 DACs and the 25GBase-CR electrical specification. Power down or follow hot-plug guidance from your hardware vendor if required, then insert each SFP28 connector into the corresponding SFP28 port until it latches. Confirm link negotiation and speed in the device management interface and check for stable status LEDs or administration indicators. For removal, release the connector latch and gently withdraw the plug following the vendor's handling instructions.

Recommendations

Use this 0.5 m SFP28 DAC for short, fixed interconnects where fiber is unnecessary and where the host hardware explicitly supports passive twinax SFP28 cables. Avoid sharp bends, excessive tensile stress, and exposure to liquids or extreme temperatures. Verify compatibility with your switch or server firmware and request a test sample in mixed environments if interoperability is critical.
