Cavo di rete DSIT CAT6 U/UTP AWG 23/1 conduttore massiccio 100 metri grigio

This CAT6 U/UTP installation cable delivers reliable Gigabit Ethernet performance over distances up to 100 meters, making it ideal for permanent building installations. Its solid bare copper conductors ensure stable, high-speed data transmission with excellent signal integrity.

Advantages

The solid AWG 23 conductors provide low attenuation and superior performance for horizontal cabling and structured wiring. The grey PVC jacket offers durability and flame retardancy, while the 250 MHz bandwidth supports demanding network applications.

Suitable for

• Horizontal cabling in office and residential buildings
• Gigabit Ethernet networks up to 1000 Mbps
• Permanent installations in walls, ceilings, and conduits
• Connecting patch panels to wall outlets

Key specifications

• Category: CAT6
• Shielding: U/UTP (Unshielded Twisted Pair)
• Conductor: Solid bare copper, AWG 23
• Length: 100 meters on reel
• Jacket: PVC, grey
• Frequency: up to 250 MHz
• Impedance: 100 Ohm
• Compliance: ISO/IEC 11801, TIA/EIA-568-C.2

Recommendations

For best performance, maintain a minimum bending radius of 4 times the outer diameter and avoid pulling tension beyond manufacturer limits. Pair with CAT6 connectors and patch panels for a complete certified installation.
