EATON PXF-25/2/003-A interruttore differenziale (RCD) 25A 2P 30mA tipo A 230V

With a 10 kA rated switching capacity and Type A sensitivity to both AC and pulsating DC residual currents, the EATON PXF-25/2/003-A delivers robust earth fault protection in a compact 2-module DIN rail format.

Overview

The EATON PXF-25/2/003-A is a two-pole residual current device (RCD) engineered for reliable protection against earth faults and direct contact with live parts. Rated at 25 A with a 30 mA residual current threshold, it is suitable for residential and commercial installations requiring dependable safety. Its Type A characteristic ensures detection of alternating and pulsating DC fault currents, making it versatile for modern electrical systems.

What stands out

• Type A RCD – detects both AC and pulsating DC residual currents
• Compact 2-module design (35mm) fits standard DIN rail enclosures
• High breaking capacity of 10 kA ensures robust protection
• Instantaneous tripping characteristic for rapid response
• IP20 protection for safe installation in distribution boards

Technical details

• Rated Current (In): 25 A
• Rated Residual Current (IΔn): 30 mA
• Rated Voltage (Un): 230 V AC
• Number of Poles: 2
• Tripping Characteristic: Instantaneous
• Rated Switching Capacity (Icn): 10 kA
• Rated Impulse Withstand Voltage (Uimp): 4 kV
• Operating Temperature Range: -25°C to +40°C
• Terminal Capacity (Solid): 1.5 - 25 mm²
• Terminal Capacity (Stranded): 1.5 - 16 mm²
• Mounting: DIN Rail (35mm)
• Standards: IEC/EN 61008-1

Our verdict

For electricians and installers seeking a dependable and compact residual current protection solution, the EATON PXF-25/2/003-A offers superior safety and performance in a space-saving design.
