EFB Electronics accoppiatore LC/APC Duplex OS2 in plastica verde, case SC Simplex

The EFB Electronics LC/APC Duplex Coupler is a high-performance fiber optic adapter designed for single-mode OS2 networks. Featuring a durable plastic housing in green and an SC-Simplex footprint, this coupler ensures reliable, low-loss connections for data centers, telecommunications, FTTH, and LAN applications.

Advantages

This coupler offers exceptional optical performance with typical insertion loss below 0.2 dB and return loss greater than 60 dB, ensuring minimal signal degradation. The zirconia ceramic ferrule provides high durability and alignment precision, supporting over 500 mating cycles. Its compact snap-in panel mount design simplifies installation in patch panels and enclosures.

Suitable for

• Data center fiber optic patching
• Telecommunications network infrastructure
• FTTH (Fiber to the Home) installations
• Local area network (LAN) fiber connections

Key specifications

• Adapter Type: LC/APC Duplex
• Fiber Mode: Single-mode (OS2)
• Connector A: LC/APC Duplex
• Connector B: LC/APC Duplex
• Housing Footprint: SC-Simplex
• Insertion Loss: < 0.2 dB (typical)
• Return Loss: > 60 dB (typical)
• Ferrule Material: Zirconia Ceramic
• Housing Material: Plastic
• Color: Green
• Mounting: Panel Mount (Snap-in)
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Durability: > 500 Mating Cycles
• Compliance: RoHS, REACH

Recommendations

For optimal performance, pair this coupler with LC/APC patch cables and ensure clean end-faces before mating. Suitable for use in both indoor and controlled outdoor environments.
