GRAFENTHAL Cavo in fibra ottica OM4 LC-LC duplex 1m aqua

The GRAFENTHAL Optical Fibre Cable OM4 is a high-performance multimode fiber optic patch cable designed for demanding data center and enterprise network environments. With LC to LC duplex connectors and a 1-meter length, this cable delivers reliable, high-speed connectivity for 10GbE, 40GbE, and 100GbE applications.

Advantages

Engineered with OM4 fiber, this cable supports high bandwidth over longer distances, making it ideal for high-density patching areas. The LSZH (Low Smoke Zero Halogen) jacket ensures safety in confined spaces, while the aqua color provides easy identification. Low insertion loss and high return loss guarantee signal integrity.

Suitable for

• Data centers requiring high-speed interconnects
• Storage Area Networks (SAN)
• Local Area Networks (LAN) with 10/40/100 Gigabit Ethernet
• Telecommunications rooms and server racks

Key specifications

• Cable Type: Fiber Optic Patch Cable
• Fiber Mode: Multimode OM4
• Connectors: LC to LC, Duplex
• Core/Cladding: 50/125 µm
• Length: 1 meter
• Jacket: LSZH, Aqua
• Insertion Loss: ≤ 0.3 dB
• Return Loss: ≥ 30 dB
• Bandwidth: 4700 MHz-km @ 850nm, 500 MHz-km @ 1300nm
• Operating Temperature: -20°C to 70°C
• Standards: TIA/EIA-568-C.3, ISO/IEC 11801, RoHS

Recommendations

For optimal performance, pair this cable with OM4-compatible transceivers and ensure proper bend radius management. Ideal for high-speed network upgrades.
