Lightwin LDP-50 LC-LC 2m OM4 cavo patch in fibra ottica multimodale, duplex, LSZH aqua LDP-50 LC-LC 2.0 OM4

Fiber optic patch cable engineered for high-speed multimode networking, delivering a robust 100 Gbps data rate over OM4 fiber with LC duplex connectors. This 2-meter LSZH jacketed cable in aqua provides reliable, low-loss connectivity for demanding data center and enterprise environments.

Advantages

OM4 laser-optimized fiber supports 10GbE, 40GbE, and 100GbE up to 150 meters, ensuring future-proof performance. Duplex LC connectors offer secure, push-pull latching for high-density patching. The LSZH jacket emits low smoke and zero halogen, enhancing safety in enclosed spaces. Low insertion loss (<0.3 dB per connector pair) and high return loss (>20 dB) maintain signal integrity. Aqua color coding enables quick identification of OM4 multimode cables.

Suitable for

• Data center backbone and server connections
• High-speed LAN and SAN applications
• 10G/40G/100G Ethernet links
• Telecommunications rooms and patch panels

Key specifications

• Cable type: Fiber optic patch cable, multimode OM4
• Connectors: LC duplex to LC duplex
• Length: 2 meters (6.56 ft)
• Core/cladding: 50/125 µm
• Jacket: LSZH, aqua
• Insertion loss: <0.3 dB per connector pair
• Return loss: >20 dB
• Attenuation: <2.3 dB/km @850nm, <0.6 dB/km @1300nm
• Bandwidth: 4700 MHz·km @850nm, 500 MHz·km @1300nm
• Operating temperature: -20°C to 70°C
• Compliance: RoHS, TIA/EIA-568-C.3, IEC 60793-2-10 Type A1a.3

Recommendations

For optimal performance, pair with OM4-compatible transceivers and ensure proper bend radius during installation. Use in environments requiring halogen-free cabling for safety compliance.
