Microconnect FIB461002 cavo InfiniBand/fibra ottica 2 m LC giallo

The Microconnect FIB461002 is a 2 m LC‑to‑LC single mode fibre optic cable (OS2) designed for high‑speed data transmission in enterprise networks, telecom rooms, server farms and cloud storage environments. With a 9 µm core diameter and yellow jacket for easy identification, this patch cord supports 1G/10G/40G/100G Ethernet links and is suitable where reliable fibre jumper cables are required.

Advantages

This OS2 single mode patch cord offers low attenuation and stable performance over long distances, enabling data transport up to 10 km at 1310 nm and up to 40 km at 1550 nm. Manufactured with LSZH cable jacket and compliant with common industry standards (IEC, EIA/TIA, Telcordia), it provides improved safety in enclosed spaces and meets professional installation requirements. The LC to LC connectors ensure compact, industry‑standard termination for high‑density panels.

Suitable for

• Enterprise network backbones and interconnects
• Telecom rooms and patch panels
• Server farms and data centre links
• Cloud storage and long‑reach Ethernet connections

Key specifications

• Length: 2 m
• Fibre type: OS2 (single mode)
• Core diameter: 9 µm
• Connectors: LC — LC
• Colour: Yellow
• Weight: 0.006 kg
• Cable jacket: LSZH

How to use

Connect one LC connector to the source transceiver or panel port and the other LC connector to the destination transceiver or port. Ensure connectors are clean and dust‑free before mating to prevent signal loss. Route the cable avoiding sharp bends and mechanical stress; maintain the manufacturer’s minimum bend radius for single mode fibre. Confirm link parameters after installation using appropriate test equipment.

Recommendations

For reliable long‑distance performance, use appropriate transceivers matched to the specified wavelengths (1310 nm or 1550 nm) and verify end‑to‑end attenuation with an optical power meter or OTDR. Store and handle the LSZH cable per standard fibre handling practices to preserve connector integrity.
