PATCHBOX C60STPXC6AXX1V cavo di rete viola 1,8 m Cat6a U/FTP (STP)

The PATCHBOX C60STPXC6AXX1V is a Cat6a flat patch cable in violet with a length of 1.8 m, designed for structured network installations and cabinet cable management. It uses U/FTP (STP) shielding to reduce electromagnetic interference and is fitted with gold-plated RJ45 connectors. The cable is intended for use with PATCHBOX® Cassettes and Frames and meets ISO/IEC 11801 Channel Class Ea and ANSI/EIA/TIA-568 Cat 6A Channel test criteria. It supports Power over Ethernet (STP: PoE; UTP: PoE++ 802.3bt Type 3, 60 W) and is RoHS compliant.

Advantages

The violet PATCHBOX Cat6a cable combines a slim, flat design for neat routing inside network cabinets with shielded U/FTP construction to limit crosstalk and external interference. Gold-plated RJ45 plugs ensure reliable contact and durability, while compliance with Cat6a channel standards provides support for 10 Gbit/s links. The cable is compatible with PATCHBOX® Cassettes and Frames for modular, space-saving installation and is suitable for PoE applications according to the specified classes.

Suitable for

• Patch connections in network cabinets using PATCHBOX® Cassettes and Frames
• 10 Gbit/s Ethernet links within data centers and server rooms
• PoE-powered devices such as access points, IP cameras, and VoIP phones (observe PoE class limits)
• Tidy horizontal and vertical cable routing where flat cable profile is required

Key specifications

• Length: 1.8 m
• Standard: Cat6a (Channel Class Ea)
• Shielding: U/FTP (STP)
• Connector: RJ45, gold-plated
• Data rate: up to 10000 Mbit/s (10 Gbit/s)
• Color: violet
• Compliance: ISO/IEC 11801 Channel Class Ea; ANSI/EIA/TIA-568 Cat 6A Channel tested; RoHS

How to use

Connect one RJ45 plug to the switch, patch panel or PATCHBOX® Cassette port and the other plug to the target device or cassette port. Route the flat cable through the PATCHBOX® Cassette and Frame channels to maintain tidy cable management and secure the cable according to your cabinet’s mounting procedure. Ensure connectors are fully inserted and locked to guarantee proper contact and signal integrity.

Recommendations

Use this U/FTP Cat6a flat cable inside PATCHBOX® modular systems and cabinet environments to keep horizontal and vertical runs compact. For maximum PoE power delivery, verify whether the connected ports and patching modules are UTP or STP and confirm PoE class support; refrain from exceeding the stated PoE classifications. Avoid tight bending below the manufacturer’s minimum bend radius to preserve performance.
